Diagenesis and porosity evolution of high-temperature and overpressure sandstone reservoirs in submarine fans of the west area of the Qiongdongnan Basin
-
摘要:
南海北部琼东南盆地西区乐东–陵水凹陷梅山组海底扇是当前天然气勘探的重点领域，且普遍具有高温超压的背景。通过薄片鉴定、图像分析、包裹体分析、X射线衍射、扫描电镜及物性测试等技术方法，结合埋藏–热演化史和油气成藏史，对琼东南盆地西区乐东–陵水凹陷梅山组海底扇储层成岩作用与孔隙演化进行研究。结果表明：海底扇储层整体以低—中孔、低—特低渗为特征，主体处于中成岩A期；成岩–成藏演化序列为早期黏土矿物→第一期烃类充注→长石微溶→第二期烃类充注→石英次生加大并且长石溶解→铁方解石、白云石胶结→硅质溶解→第三期烃类充注及CO2充注→碳酸盐胶结物微溶；孔隙演化为“先超压、后成藏、再致密化”模式，表现出“压实明显减孔，胶结减孔，超压保孔、溶蚀适量增孔”的特点。
Abstract:Submarine fans in the west area of the Qiongdongnan Basin, located on the continental shelf in the northern of the South China Sea, are the main area for gas exploration. These submarine fans are commonly characterized by high-temperature and overpressure diagenetic environments. A comprehensive analysis was conducted to evaluate diagenesis and porosity evolution of submarine fan reservoirs in the Meishan Formation of the Ledong-Lingshui Sag in the west area of the Qiongdongnan Basin. The analysis incorporates thin-section identification, image analysis, fluid inclusion analysis, clay X-ray diffraction, scanning electron microscope (SEM), and physical property test, with comprehensive consideration of the burial-thermal and hydrocarbon charging history of the reservoirs. The results show that the submarine fan reservoirs are in the A-mesodiagenesis stage, with reservoirs exhibiting low to moderate porosity and low to extra-low permeability. The diagenetic and accumulation sequence progresses as follows: early clay mineral precipitation → first phase of accumulation → feldspar micro-dissolution → second phase of accumulation → quartz overgrowth and intense feldspar dissolution → ferrocalcite and dolomite cementation → quartz and quartz overgrowth dissolution → third phase of accumulation and CO2 charging → micro-dissolution of carbonate cements. The porosity evolution model follows a "first overpressure, later accumulation, and then compaction" pattern, characterized by "significant porosity reduction due to compaction; porosity reduction from ferrocalcite cementation; porosity conservation under overpressure conditions; moderate porosity increase due to dissolution".
-
-
表 1 乐东–陵水凹陷梅山组储集岩统计表
Table 1. Statistics of reservoir rocks in Meishan Formation, Ledong-Lingshui Sag
层位 井名 深度/m 泥岩 粉砂岩 细砂岩 中砂岩 砂砾岩 总厚度/m 厚度/m 百分比/% 厚度/m 百分比/% 厚度/m 百分比/% 厚度/m 百分比/% 厚度/m 百分比/% 梅
山
组SW-1 3409 ～3888 212 49.2 186 43.2 33 7.7 / / / / 431 S-1 3302 ～3640 255.46 75.6 82.54 24.4 / / / / / / 338 S-2 3349 ～3812 382.06 82.5 80.94 17.5 / / / / / / 463 SW-2 3475 ～3941 211 45.3 255 54.7 / / / / / / 466 B-2 4817 ～5282 95 31.6 9 3.0 157 52.2 19.5 6.5 20 6.7 300.5 C-1 3800 ～4053 114 45.1 68.0 26.9 57.0 22.5 14.0 5.5 / / 253 WS-1 4322 ～4448 50 39.7 23.0 18.3 53.0 42.1 / / / / 126
下载: 导出CSV
-
[1] Beard D C,Weyl P K,1973. Influence of texture on porosity and permeability of unsolidated sand[J]. AAPG Bulletin,57(2):349 − 369.
[2] 卞雅倩,傅强,刘金水,等,2023. 东海陆架盆地丽水西凹古新统砂岩储层成岩作用及成岩演化[J]. 沉积与特提斯地质,43(4):688 − 701.
Bian Y Q,Fu Q,Liu J S,et al.,2023. Diagenesis and diagenetic evolution of Paleocene sandstone seservoirs in Lishui West Sag,East China Sea shelf basin[J]. Sedimentary Geology and Tethyan Geology,43(4):688 − 701 (in Chinese with English abstract).
[3] 操应长,葸克来,王艳忠,等,2013. 冀中坳陷廊固凹陷河西务构造带古近系沙河街组四段储集层孔隙度演化定量研究[J]. 古地理学报,15(5):593 − 601.
Cao Y C,Xi K L,Wang Y Z,et al.,2013. Quantitative researchon porosity evolution of reservoirs in the Member 4 of Paleogene Shahejie Formation in Hexiwu structural zone of Langgu sag,Jizhong Depression[J]. Journal of Palaeogeography,15(5):593 − 601 (in Chinese with English abstract).
[4] 陈志鹏,鲍志东,任战利,等,2017. 尼日尔三角洲盆地某油田深水海底扇沉积特征[J]. 地质科技情报,36(3):174 − 181.
Chen Z P,Bao Z D,Ren Z L,et al.,2017. Sedimentary characteristics of a submarine fan of an oilfield in Niger Basin[J]. Geological Science and Technology Information,36(3):174 − 181 (in Chinese with English abstract).
[5] 杜春阳,唐闻强,杜秋定,等,2023. 柴达木盆地冷湖地区侏罗系致密砂岩储层特征与控制因素[J]. 沉积与特提斯地质,43(3):501 − 514.
Du C Y,Tang W Q,Du Q D,et al.,2023. Characteristics and controlling factors of tight sandstone reservoir of the Jurassic strata in the Lenghu region,Northern Qaidam Basin[J]. Sedimentary Geology and Tethyan Geology,43(3):501 − 514 (in Chinese with English abstract).
[6] 杜文波,聂鑫,杨楚鹏,等,2022. 南海北部珠江口外峡谷体系沉积 特征、演化及其控制因素[J]. 地球科学,47(11):4046 − 4059.
Du W B,Nie X,Yang C P,et al.,2022. Sedimentary characteristics,evolution and controlling factors of the Pearl River canyon system in the northern South China Sea[J]. Earth Science,47(11):4046 − 4059 (in Chinese with English abstract).
[7] 范彩伟,胡林,李明,等,2021. 琼东南盆地深水区圈闭有效性评价方法及其应用[J]. 中国海上油气,33(5):1 − 13.
Fan C W,Hu L,Li M,et al.,2021. Evaluation method of trap effectiveness in deep water area of Qiongdongnan basin and its application[J]. China Offshore Oil and Gas,33(5):1 − 13 (in Chinese with English abstract).
[8] 甘军,梁刚,李兴,等,2022. 琼东南盆地梅山组海底扇天然气成因类型及成藏模式[J]. 地质学报,96(3):1069 − 1078.
Gan J,Liang G,Li X,et al.,2022. Genetic types and accumulation model of submarine fan gas in the Meishan Formation,Qiongdongnan basin[J]. Acta Geologica Sinica,96(3):1069 − 1078 (in Chinese with English abstract).
[9] 高媛,曲希玉,杨希冰,等,2018. 琼东南盆地乐东—陵水凹陷中新统储层流体包裹体特征及成藏期研究[J]. 海相油气地质,23(1):83 − 90.
Gao Y,Qu X Y,Yang X B,et al.,2018. Characteristics of fluid inclusions and accumulation period of Miocene reservoir in Ledong-Lingshui Sag of Qiongdongnan Basin[J]. Marine Origin Petroleum Geology,23(1):83 − 90 (in Chinese with English abstract).
[10] 李安琪,胡林,王真真,等,2021. 琼东南盆地乐东凹陷梅山组海底扇沉积演化及油气地质意义[J]. 油气地质与采收率,28(2):76 − 84.
Li A Q,Hu L,Wang Z Z,et al.,2021. Sedimentary evolution of Meishan Formation submarine fan in Ledong Sag,Qiongdongnan Basin and its significance in hydrocarbon exploration[J]. Petroleum Geology and Recovery Efficiency,28(2):76 − 84 (in Chinese with English abstract).
[11] Li D W,Gong C L,Fan G Z,et al.,2023. Morphological and architectural evolution of submarine channels:An example from the world's largest submarine fan in the Bay of Bengal[J]. Marine and Petroleum Geology,155(9):106347 − 106368.
[12] 罗泉源,焦祥燕,刘昆,等,2020. 乐东−陵水凹陷梅山组海底扇识别及沉积模式[J]. 海洋地质与第四纪地质,40(2):90 − 99.
Luo Q Y,Jiao X Y,Liu K,et al.,2020. Identification of submarine fan in the Meishan Formation of the Ledong-Lingshui Sag in the Qiongdongnan Basin and its depositional model[J]. Marine Geology & Quaternary Geology,40(2):90 − 99 (in Chinese with English abstract).
[13] Scherer M,1987. Parameters influencing porosity in sandstones:A model for sandstone porosity predication[J]. AAPG Bulletin,71(5):485 − 491.
[14] 苏龙,郑建京,王琪,等,2012. 琼东南盆地超压研究进展及形成机制[J]. 天然气地球科学,23(4):662 − 672.
Su L,Zheng J J,Wang Q,et al.,2012. Formation mechanism and research progress on overpressure in the Qiongdongnan Basin[J]. Natural Gas Geoscience,23(4):662 − 672 (in Chinese with English abstract).
[15] 税蕾蕾,梁茹,孟祥豪,等,2020. 莺歌海盆地乐东地区石英裂隙内流体包裹体特征及其对天然气成藏制约[J]. 沉积与特提斯地质,40(1):45 − 52.
Shui L L,Liang R,Meng X H,et al.,2020. Characteristics of fluid inclusions in quartz fractures in Ledong area of Yinggehai Basin and its constraints on gas accumulation[J]. Sedimentary Geology and Tethyan Geology,40(1):45 − 52 (in Chinese with English abstract).
[16] Sun R,Yao X Z,Wang X Y,et al.,2022. Source-to-sink system and sedimentary characteristics of the lower Miocene submarine fans in the eastern deep water area of the Qiongdongnan Basin,northern South China Sea[J]. Frontiers in Earth Science,10:956594. doi: 10.3389/feart.2022.956594
[17] 万友利,冯兴雷,赵瞻,等,2022. 羌塘盆地南坳陷布曲组白云岩储层孔喉结构及其分形特征研究[J]. 沉积与特提斯地质,42(3):481 − 496.
Wan Y L,Feng X L,Zhao Z,et al.,2022. Pore-throat structure and fractal characteristics of dolomite reservoir in the Buqu Formation in the southern depression,Qiangtang Basin[J]. Sedimentary Geology and Tethyan Geology,42(3):481 − 496 (in Chinese with English abstract).
[18] 王永凤,王英民,李冬,等,2011. 珠江口盆地坡折带特征及其对沉积体系的控制[J]. 沉积与特提斯地质,31(3):1 − 6.
Wang Y F,Wang Y M,Li D,et al.,2011. Characteristics of the slope break zones and their controls on the depositional systems in the Pearl River Mouth Basin[J]. Sedimentary Geology and Tethyan Geology,31(3):1 − 6 (in Chinese with English abstract).
[19] 王艳忠,操应长,葸克来,等,2013. 碎屑岩储层地质历史时期孔隙度演化恢复方法——以济阳坳陷东营凹陷沙河街组四段上亚段为例[J]. 石油学报,34(6):1100 − 1111.
Wang Y Z,Cao Y C,Xi K L,et al.,2013. A recovery method for porosity evolution of clastic reservoirs with geological time:A case study from the upper submember of Es4 in the Dongying depression,Jiyang Subbasin[J]. Acta Petrolei Sinica,34(6):1100 − 1111 (in Chinese with English abstract).
[20] 吴迅达,廖晋,孙文钊,等,2021. 莺歌海盆地天然气运聚成藏条件与分布富集规律[J]. 地质力学学报,27(6):963 − 974.
Wu X D,Liao J,Sun W Z,et al.,2021. Natural gas distribution and reservoir-forming law of the Yinggehai Basin,China[J]. Journal of Geomechanics,27(6):963 − 974 (in Chinese with English abstract).
[21] 徐强,李冬,朱伟林,等,2020. 晚中新世红河海底扇碎屑锆石SHRIMP U-Pb年龄:物源区制约及红河袭夺事件探讨[J]. 沉积与特提斯地质,40(3):20 − 30.
Xu Q,Li D,Zhu W L,et al.,2020. SHRIMP U-Pb ages of detrital zircons:Discussions on provenance control and the Red River Capture Event[J]. Sedimentary Geology and Tethyan Geology,40(3):20 − 30 (in Chinese with English abstract).
[22] 尤丽,江汝锋,徐守立,等,2021. 琼东南盆地深水区乐东−陵水凹陷梅山组天然气成藏特征与勘探潜力[J]. 中国海上油气,33(5):24 − 31.
You L,Jiang R F,Xu S L,et al.,2021. Accumulation characteristics and exploration potential of Meishan Formation gas in Ledong-Lingshui sag,deep water area of Qiongdongnan basin[J]. China Offshore Oil and Gas,33(5):24 − 31 (in Chinese with English abstract).
[23] 赵燚林,马遵青,陈国俊,等,2019. 琼东南盆地松南−宝岛凹陷梅山组碎屑岩储集性及成岩作用研究[J]. 沉积与特提斯地质,39(4):14 − 26.
Zhao Y L,Ma Z Q,Chen G J,et al.,2019. Physical properties and diagenesis of the clastic rocks from the Meishan Formation in the Songnan-Baodao depression,Qiongdongnan Basin[J]. Sedimentary Geology and Tethyan Geology,39(4):14 − 26 (in Chinese with English abstract).
[24] 郑潇宇,张翔,李建,等,2023. 塔里木盆地西北地区震旦系苏盖特布拉克组潮坪相碎屑岩成岩作用与成岩演化研究[J]. 沉积与特提斯地质,43(3):530 − 541.
Zheng X Y,Zhang X,Li J,et al.,2023. Diagenesis and diagenetic evolution of tidal flat facies clastic rocks of Sinian Sugetbrak Formation in Northwest Tarim Basin[J]. Sedimentary Geology and Tethyan Geology,43(3):530 − 541 (in Chinese with English abstract).
[25] 钟泽红,刘景环,张道军,等,2013. 莺歌海盆地东方区大型海底扇成因及沉积储层特征[J]. 石油学报,34(S2):102 − 111.
Zhong Z H,Liu J H,Zhang D J,et al.,2013. Origin and sedimentary reservoir characteristics of a large submarine fan in Dongfang area,Yinggehai Basin[J]. Acta Petrolei Sinica,34(S2):102 − 111 (in Chinese with English abstract).
[26] 朱光辉,陈刚,刁应护,2000. 琼东南盆地温压场特征及其与油气运聚的关系[J]. 中国海上油气:地质,14(1):30 − 37.
Zhu G H,Chen G,Diao Y H,et al.,2000. Characteristics of geotherm-pressure field and its relationship with hydrocarbon migration and accumulation in Qiongdongnan Basin,South China Sea[J]. China Offshore Oil and Gas(Geology),14(1):30 − 37 (in Chinese with English abstract).
[27] 左倩媚,张道军,王亚辉,等,2016. 琼东南盆地深水区新近系海底扇沉积特征与资源潜力[J]. 海洋学报,38(11):105 − 116.
Zuo Q M,Zhang D J,Wang Y H,et al.,2016. Sedimentary characteristics and exploration potential of Neogene submarine fan in the deepwater area of the Qiongdongnan Basin[J]. Haiyang Xuebao,38(11):105 − 116 (in Chinese with English abstract).
-
