Experimental Study on Ultra-fine Grinding of a Phosphate Ore in Hebei Province by Stirred Mill
-
摘要:
这是一篇矿物加工工程领域的论文。采用超细粉磨技术处理磷矿，可改变磷矿中含磷矿物的物理化学性质，从而提高磷矿中磷的溶解与释放，使其可作为磷肥使用。搅拌磨机作为超细粉磨设备，用其处理磷矿的可行性与工艺参数对磨矿效果影响的研究尚不完善。本文采用立式搅拌磨机对河北某磷矿进行湿法磨矿实验，粉磨产品的粒度分布通过NKT6100-D型激光粒度仪进行检测，探究磨矿工艺参数对产品粒度组成以及新生成粒级含量的影响，并通过R-R方程将产品粒度参数化分析，确定较适宜的工艺参数。结果表明，在搅拌器转速550 r/min、磨矿浓度65%、充填率60%、料球比0.5和磨矿时间30 min的条件下，获得有效磷含量和枸溶率分别为8.75%和74.03%，颗粒特征参数b为0.371、均匀性系数n为1.426的粉磨产品，可见用搅拌磨机对磷矿进行超细粉磨处理是可行的。
Abstract:This is a paper in the field of mineral processing engineering. Application of ultra-fine grinding technology to treat phosphate ore can change the physical and chemical properties of phosphate containing minerals in phosphate ore, thus improving the dissolution and release of phosphorus in phosphate ore, so that it can be used as phosphate fertilizer. As an ultra-fine grinding equipment, the feasibility of using stirred mill to treat phosphate ore and the research on the influence of process parameters on grinding effect are not perfect. A phosphate ore in Hebei Province was wet ground by a vertical stirring mill in this paper.The particle size distribution of the ground product was detected by NKT6100-D laser particle size analyzer.The effect of grinding process parameters on the particle size composition of product and the content of newly formed particles was explored, and the product particle size was parametrically analyzed by R-R equation to determine the more appropriate operating process parameters. The results showed that under the conditions of agitator speed of 550 r/min, grinding concentration of 65%, filling rate of 60%, feed to ball ratio of 0.5 and grinding time of 30 min, the available phosphorus content and phosphorus solubility in citric acid of 8.75% and 74.03%, particle characteristic parameter b of 0.371 and uniformity coefficient n of 1.426 were obtained. It can be seen that it is feasible to use a vertical stirring mill for ultra-fine grinding of phosphate ore.
-
-
表 1 磷精矿化学多元素分析结果/%
Table 1. Results of chemical multi-element analysis of phosphate concentrate
P2O5 CaO SiO2 Al2O3 MgO TFe F 27.07 41.92 12.25 2.77 1.84 5.50 2.17
下载: 导出CSV
表 2 不同搅拌器转速下粉磨产品R-R方程回归结果
Table 2. Regression results of R-R equation for milling products with different stirrer revolving speed
转速/（r·min-1） 350 400 450 500 550 b 0.195 0.218 0.230 0.267 0.306 n 1.147 1.152 1.180 1.142 1.121 R2 0.997 0.996 0.995 0.995 0.998
下载: 导出CSV
表 3 不同磨矿浓度下粉磨产品R-R方程回归结果
Table 3. Regression results of R-R equation for milling products with different pulp concentrations
磨矿浓度/% 50 55 60 65 70 b 0.275 0.289 0.324 0.342 0.298 n 1.116 1.152 1.215 1.208 1.164 R2 0.997 0.997 0.997 0.997 0.992
下载: 导出CSV
表 4 不同充填率下粉磨产品R-R方程回归结果
Table 4. Regression results of R-R equation for milling products with different filling rates
充填率/% 40 45 50 55 60 65 70 b 0.320 0.334 0.326 0.385 0.383 0.391 0.386 n 1.134 1.127 1.167 1.224 1.473 1.404 1.231 R2 0.997 0.997 0.997 0.998 0.999 0.998 0.998
下载: 导出CSV
表 5 不同料球比下粉磨产品R-R方程回归结果
Table 5. Regression results of R-R equation of milling products with different ratio of material to ball
料球比 0.3 0.4 0.5 0.6 0.7 b 0.341 0.354 0.369 0.373 0.355 n 1.478 1.536 1.579 1.388 1.241 R2 0.998 0.998 0.998 0.997 0.993
下载: 导出CSV
表 6 不同磨矿时间下粉磨产品R-R方程回归结果
Table 6. Regression results of R-R equation for milling products with different grinding time
时间/min 10 20 30 40 50 b 0.206 0.327 0.371 0.384 0.366 n 1.067 1.236 1.426 1.507 1.650 R2 0.989 0.991 0.996 0.998 0.996
下载: 导出CSV
-
[1] CORDELL D, ROSEMARIN A, Schröder JJ, et al. Towards global phosphorus security: A systems framework for phosphorus recovery and reuse options[J]. Chemosphere, 2011, 84(6):747-758. doi: 10.1016/j.chemosphere.2011.02.032
[2] 王涛, 付磊, 李宁. 某硅钙质胶磷矿正反浮选实验研究[J]. 矿产综合利用, 2020(20):91-95. WANG T, FU L, LI N. Study on direct-reverse flotation of a silica calcinate phosphate ore[J]. Multipurpose Utilization of Mineral Resources, 2020(20):91-95.
WANG T, FU L, LI N. Study on direct-reverse flotation of a silica calcinate phosphate ore[J]. Multipurpose Utilization of Mineral Resources, 2020(20): 91-95.
[3] 薛天星, 熊先孝, 田升平. 中国磷矿主要矿集区及其资源潜力探讨[J]. 化工矿产地质, 2011, 33(1):9-20. XUE T X, XIONG X X, TIAN S P. Discussion on the principal phosphorite-concentrated districts and the resource poteneial in China[J]. Geology of Chemical Minerals, 2011, 33(1):9-20. doi: 10.3969/j.issn.1006-5296.2011.01.002
XUE T X, XIONG X X, TIAN S P. Discussion on the principal phosphorite-concentrated districts and the resource poteneial in China[J]. Geology of Chemical Minerals, 2011, 33(1): 9-20. doi: 10.3969/j.issn.1006-5296.2011.01.002
[4] 张亚明, 王海军, 赵玉凤, 等. 磷矿资源综合利用效益评价体系研究[J]. 中国矿业, 2019, 28(9):54-58+84. ZHANG Y M, WANG H J, ZHAO Y F, et al. Study on the evaluation system of comprehensive utilization efficiency of phosphate resources[J]. China Mining Magazine, 2019, 28(9):54-58+84.
ZHANG Y M, WANG H J, ZHAO Y F, et al. Study on the evaluation system of comprehensive utilization efficiency of phosphate resources[J]. China Mining Magazine, 2019, 28(9): 54-58+84.
[5] 王晨, 高宏, 刘淑红, 等. 中低品位磷矿粉的机械力化学活化与活性表征[J]. 化工矿物与加工, 2012, 41(7):1-4. WANG C, GAO H, LIU S H, et al. Mechano-chemical activity and the characterization of activity for low-grade phosphate powder[J]. Industrial Minerals & Processing, 2012, 41(7):1-4. doi: 10.3969/j.issn.1008-7524.2012.07.001
WANG C, GAO H, LIU S H, et al. Mechano-chemical activity and the characterization of activity for low-grade phosphate powder[J]. Industrial Minerals & Processing, 2012, 41(7): 1-4. doi: 10.3969/j.issn.1008-7524.2012.07.001
[6] 肖骏, 陈代雄, 覃文庆, 等. 某细粒浸染高硫难选铅锌矿选矿新工艺研究[J]. 矿冶, 2014, 23(2):5-10. XIAO J, CHEN D X, QIN W Q, et al. Study on new mineral processing technology forafinely disseminated high-sulfur referactory lead-zin core[J]. Mining and Metallurgy, 2014, 23(2):5-10. doi: 10.3969/j.issn.1005-7854.2014.02.002
XIAO J, CHEN D X, QIN W Q, et al. Study on new mineral processing technology forafinely disseminated high-sulfur referactory lead-zin core[J]. Mining and Metallurgy, 2014, 23(2): 5-10. doi: 10.3969/j.issn.1005-7854.2014.02.002
[7] 张国旺, 刘雅琛, 赵湘, 等. 立式搅拌磨矿机干法超细粉磨重钙的研究[J]. 中国粉体技术, 2000(S1):128-131. ZHANG G W, LIU Y C, ZHAO X, et al. Study on dry ultra-fine grinding of heavy calcium by vertical stirred mill[J]. China Powder Science and Technology, 2000(S1):128-131.
ZHANG G W, LIU Y C, ZHAO X, et al. Study on dry ultra-fine grinding of heavy calcium by vertical stirred mill[J]. China Powder Science and Technology, 2000(S1): 128-131.
[8] 单志伟, 李凤久, 刘立伟, 等. 超细粉磨活化河北某磷矿粉实验研究[J]. 矿产综合利用, 2020(2):55-59. SHAN Z W, LI F J, LIU L W, et al. Experimental study on activation of a phosphate rock powder in Hebei by ultrafine grinding[J]. Multipurpose Utilization of Mineral Resources, 2020(2):55-59.
SHAN Z W, LI F J, LIU L W, et al. Experimental study on activation of a phosphate rock powder in Hebei by ultrafine grinding[J]. Multipurpose Utilization of Mineral Resources, 2020(2): 55-59.
[9] 李营营, 李国峰, 单志伟, 等. 湿式粉磨提高某磷矿粉释磷特性研究[J]. 矿产综合利用, 2022(4):188-192. LI Y Y, LI G F, SHAN Z W, et al. Study on improvement of phosphorus release characteristics of aphosphaterock powder by wet grinding[J]. Multipurpose Utilization of Mineral Resources, 2022(4):188-192.
LI Y Y, LI G F, SHAN Z W, et al. Study on improvement of phosphorus release characteristics of aphosphaterock powder by wet grinding[J]. Multipurpose Utilization of Mineral Resources, 2022(4): 188-192.
[10] 张平, 孟磊, 石元亮. 不同类型磷矿石的机械活化效果研究[J]. 化工矿物与加工, 2014, 43(8):13-15+19. ZHANG P, MENG L, SHI Y L. Study on the effects of mechanical activation on different kinds of phosphate rock[J]. Chemical Minerals and Processing, 2014, 43(8):13-15+19. doi: 10.16283/j.cnki.hgkwyjg.2014.08.007
ZHANG P, MENG L, SHI Y L. Study on the effects of mechanical activation on different kinds of phosphate rock[J]. Chemical Minerals and Processing, 2014, 43(8): 13-15+19. doi: 10.16283/j.cnki.hgkwyjg.2014.08.007
[11] 宋晓岚, 邱冠周, 杨华明. 机械化学及其应用研究进展[J]. 金属矿山, 2004(11):34-38. SONG X L, QIU G Z, YANG H M. Mechanochemistry and advances in its application research[J]. Metal Mine, 2004(11):34-38. doi: 10.3321/j.issn:1001-1250.2004.11.010
SONG X L, QIU G Z, YANG H M. Mechanochemistry and advances in its application research[J]. Metal Mine, 2004(11): 34-38. doi: 10.3321/j.issn:1001-1250.2004.11.010
-
