Desilication Research of Sichuan Phosphogypsum by Flotation
-
摘要:
这是一篇矿物加工工程领域的论文。磷石膏是生产湿法磷酸时产生的副产物。目前，我国磷石膏每年新增排放量较大，存在环保和安全风险，严重制约了磷化工企业的可持续健康发展。针对四川磷石膏中二氧化硅含量高的问题，采用反浮选工艺进行了磷石膏脱硅实验研究。实验结果表明，在矿浆自然pH值为5.3，采用BK421B为捕收剂，通过“一粗一精一扫，中矿顺序返回”的反浮选工艺流程，可以获得产率为89.63%，二水硫酸钙品位为96.85%、SiO2含量为1.85%，二水硫酸钙回收率96.72%的石膏精矿，取得了良好的选矿指标，为磷石膏的资源化利用提供了技术支持。
Abstract:This is a paper in the field of mineral processing engineering. Phosphogypsum is a by-product produced during the production of wet process phosphoric acid. At present, China's phosphogypsum has a large annual new emissions, environmental and safety risks, which seriously restrict the sustainable and healthy development of phosphorus chemical enterprises.In order to solve the problem of high silica content in Sichuan phosphogypsum, the desilication tests werecarried by reverse flotation process.The test results showed that through reverse flotation process of "one roughing, one cleaning, one scavenging, middling returning in sequence", gypsum concentrate was obtained with yield of 89.63%, grading 1.85% SiO2, grading 96.85% calcium sulfate dihydrate with recovery of 96.72%, under conditions of pulp pH valuewith 5.3, BK421B as collector. The research provides technical support for resource utilization of phosphogypsum.
-
Key words:
- Phosphogypsum /
- Mineral processing engineering /
- Harvesting agents /
- Desilication /
- Flotation
-
-
表 1 磷石膏主要化学成分及含量/%
Table 1. Main chemical composition of phosphogypsum
CaO SO3 SiO2 Fe K2O Na2O Al2O3 P2O5 MgO C 31.58 41.25 5.72 0.098 0.096 0.16 0.38 0.95 0.083 0.068
下载: 导出CSV
表 2 磷石膏粒度筛析结果
Table 2. Screening results of phosphogypsum
粒级/mm 产率/% 负累计/% +0.2 0.52 100.00 -0.2+0.15 1.66 99.48 -0.15+0.105 3.50 97.81 -0.105+0.074 22.86 94.32 -0.074+0.045 21.85 71.46 -0.045+0.038 5.20 49.61 -0.038+0.030 12.74 44.41 -0.030 31.67 31.67 合计 100.00
下载: 导出CSV
表 3 闭路实验结果
Table 3. Results of locked-cycle test
产品名称 产率/% 品位/% 回收率/% CaSO4·2H2O SiO2 CaSO4·2H2O SiO2 精矿 89.63 96.85 1.85 96.72 27.88 尾矿 10.37 28.36 41.36 3.28 72.12 原矿 100.00 89.75 5.95 100.00 100.00
下载: 导出CSV
-
[1] 朱鹏程, 王国栋, 曾波. 磷石膏浮选脱硅试验研究[J]. 矿产综合利用, 2014, 35(6):39-42. ZHU P C, WANG G D, ZENG B. Experimental study on phosphogypsum desilication by flotation[J]. Multipurpose Utilization of Mineral Resources, 2014, 35(6):39-42. doi: 10.3969/j.issn.1000-6532.2014.06.010
ZHU P C, WANG G D, ZENG B. Experimental study on phosphogypsum desilication by flotation[J]. Multipurpose Utilization of Mineral Resources, 2014, 35(6): 39-42. doi: 10.3969/j.issn.1000-6532.2014.06.010
[2] 朱鹏程, 曾波, 王国栋. H2-Z捕收剂正浮选石膏性能研究[J]. 矿冶工程, 2015, 35(1):54-56+60. ZHU P C, ZENG B, WANG G D. Study on the performance of H2-Z trap for positive flotation of gypsum[J]. Mineral and Metallurgical Engineering, 2015, 35(1):54-56+60. doi: 10.3969/j.issn.0253-6099.2015.01.015
ZHU P C, ZENG B, WANG G D. Study on the performance of H2-Z trap for positive flotation of gypsum [J]. Mineral and Metallurgical Engineering, 2015, 35(1): 54-56+60. doi: 10.3969/j.issn.0253-6099.2015.01.015
[3] 唐湘平, 李超, 黄云阶, 等. 四川某地磷石膏开发利用实验[J]. 矿产综合利用, 2019(5):28-31. TANG X P, LI C, HUANG Y J, et al. Experimental study on development and utilization of phosphogypsum in Sichuan[J]. Multipurpose Utilization of Mineral Resources, 2019(5):28-31. doi: 10.3969/j.issn.1000-6532.2019.05.006
TANG X P, LI C , HUANG Y J, et al. Experimental study on development and utilization of phosphogypsum in Sichuan[J]. Multipurpose Utilization of Mineral Resources, 2019(5): 28-31. doi: 10.3969/j.issn.1000-6532.2019.05.006
[4] 胡敏, 彭丽, 郭娜, 等. 磷石膏- 炭化污泥胶凝材料力学性能试验研究[J]. 矿产综合利用, 2020(4):196-201. HU M, PENG L, GUO N, et al. Study on mechanical properties of phosphogypsum-carbonized sludge composite cementitious materials[J]. Multipurpose Utilization of Mineral Resources, 2020(4):196-201. doi: 10.3969/j.issn.1000-6532.2020.04.034
HU M, PENG L, GUO N, et al. Study on mechanical properties of phosphogypsum-carbonized sludge composite cementitious materials[J]. Multipurpose Utilization of Mineral Resources, 2020(4): 196-201. doi: 10.3969/j.issn.1000-6532.2020.04.034
[5] 国亚非, 赵泽阳, 张正虎, 等. 磷石膏的综合利用探讨[J]. 中国非金属工业导刊, 2021(4):4-7. GUO Y F, ZHAO Z Y, ZHANG Z H, et al. Exploration of comprehensive utilization of phosphogypsum[J]. China Nonmetal Industry Journal, 2021(4):4-7.
GUO Y F, ZHAO Z Y, ZHANG Z H, et al. Exploration of comprehensive utilization of phosphogypsum[J]. China Nonmetal Industry Journal, 2021(4): 4-7.
[6] 杜明霞, 王进明, 董发勤, 等. 磷石膏工艺矿物学特征与可选性关系研究[J]. 非金属矿, 2020(6):52-55. DU M X, WANG J M, DONG F Q, et al. Study on the relationship between mineralogical characteristics and optionality of phosphogypsum process[J]. Nonmetallic Minerals, 2020(6):52-55. doi: 10.3969/j.issn.1000-8098.2020.06.015
DU M X, WANG J M, DONG F Q, et al. Study on the relationship between mineralogical characteristics and optionality of phosphogypsum process[J]. Nonmetallic Minerals, 2020(6): 52-55. doi: 10.3969/j.issn.1000-8098.2020.06.015
-
