Experimental Study on Flotation Process of a Barite Mine in Northwest China
-
摘要:
这是一篇矿物加工工程领域的论文。针对西北某重晶石矿分布不均匀、嵌布粒度粗细不均、重晶石与石英嵌布关系极为密切等特点，进行了详细的选矿工艺实验研究，研究结果表明：水玻璃作为抑制剂、氧化石蜡皂作为捕收剂可有效实现硫酸钡与脉石的分选，采用快速+强化浮选工艺，减轻了精选作业负荷、强化了硫酸钡的综合回收，小型闭路浮选实验获得重晶石精矿中硫酸钡品位89.16%、SiO2品位0.85%，硫酸钡回收率92.01%的较好技术指标，重晶石精矿产品品质达到钻井用重晶石粉质量标准。
Abstract:This is a paper in the field of mineral processing engineering. According to the characteristics of a certain barite ore in Northwest China, such as uneven distribution of barite ore, uneven dissemination particle size of barite, and extremely close dissemination relationship between barite and quartz, a detailed beneficiation process test was carried out. The research results show that: Sodium silicate as depressant, oxygen fossil sodium soap as a collector, which can effectively realize the barium sulfate and gangue separation, using fast segmentation strengthened flotation technology, reduce the selected operation load and strengthening the comprehensive recovery of barium sulfate, small closed-circuit flotation tests with the grade of barium sulfate in the barite ore concentrate 89.16%, the SiO2 grade is 0.85%, recovery rate of barium sulfate 92.01% better technical index, barite ore concentrate products meet brick wells with barite powder quality standards.
-
-
表 1 原矿多元素分析结果 /%
Table 1. Chemical analysis results of the samples
BaSO4 BaCO3 TFe Pb Zn Cu As P2O5 SiO2 Al2O3 CaO MgO MnO SrO2 Cd 61.51 4.46 4.26 0.006 0.07 0.06 <0.05 0.005 23.74 0.78 0.93 0.24 0.95 0.65 <0.01
下载: 导出CSV
表 2 重选实验结果
Table 2. Result of gravity separation
粒级/mm 产品名称 产率/% BaSO4品位/% BaSO4回收率/% -2+0.833 精 矿 83.45 67.45 91.93 尾 矿 16.55 29.87 8.07 原 矿 100.00 61.23 100.00 -0.833+0.147 精 矿 67.21 68.34 80.26 尾 矿 32.79 34.46 19.74 原 矿 100.00 57.23 100.00 -0.147 精 矿 54.87 77.45 68.17 尾 矿 45.13 43.97 31.83 原 矿 100.00 62.34 100.00
下载: 导出CSV
表 3 闭路浮选实验结果
Table 3. Results of the closed-circuit flotation test
浮选工艺 产品名称 产率/
%BaSO4
品位/%BaSO4
回收率/%传统浮选工艺 精 矿 63.42 87.78 90.51 尾 矿 36.58 15.96 9.49 原 矿 100.00 61.51 100.00 快速+强化浮选工艺 精矿1 30.18 92.72 45.50 精矿2 33.29 85.94 46.51 加权总精矿 63.47 89.16 92.01 尾 矿 36.53 13.46 7.99 原 矿 100.00 61.51 100.00
下载: 导出CSV
表 4 快速+强化浮选工艺重晶石精矿产品检测结果
Table 4. Test results of barite concentrate products by rapid and enhanced flotation process
名称 BaSO4 BaCO3 TFe SiO2 Al2O3 CaO MgO MnO SrO2 含量/% 89.16 3.81 1.34 0.87 0.36 0.19 0.27 0.22 0.37 项目 密度
/ (g·cm-3)细度/% 粘度效应/mPa·s 0.074孔径筛筛余量 0.043孔径筛筛余量 加硫酸钙前 加硫酸钙后 测定结果 4.31 2.57 4.82 47 45
下载: 导出CSV
-
[1] 李春阳, 田升平, 牛桂芝. 中国重晶石矿主要矿集区及其资源潜力探讨[J]. 化工矿产地质. 2010, 6(2) : 75-86
LI C Y, TIAN S P, NIU G Z. Discussion on china barite-concentrating area and the resource potential[J]. Geology of Chemical Minerals. , 2010, 6(2) : 75-86.
[2] 李占远. 我国重晶石资源分布与开发前景[J]. 中国非金属矿工业导刊. 2004, 20(5) : 86-88.
LI Z Y. Distribution and development prospect of barite resources in China [J]. China Non-metallic Minerals Industry. 2004, 20(5) : 86-88.
[3] 童义隆, 罗惠华, 舒超, 等. 贵州重晶石与方解石常温浮选分离实验研究[J]. 矿产综合利用, 2020(1): 54-58.
TONG Y L, LUO H H, SU C, et al. Research on flotation test of separation of barite and calcite from Guizhou at normal temperature[J]. Multipurpose Utilization of Mineral Resources, 2020(1): 54-58
[4] 王洋, 黄聪, 李珍. 重晶石资源现状及材料化应用[J]. 矿产保护与利用, 2020, 40(6): 26-32.
WANG Y, HUANG C, LI Z. Status quo and materialized application of barite resources [J]. Conservation and Utilization of Mineral Resources. 2020, 40(6): 26-32.
[5] 高扬, 刘全军, 宋建文. 贵州某低品位重晶石矿选矿试验研究[J]. 化工矿物与加工, 2017, 46(7):17-20. GAO Y, LIU Q J, SONG J W. Flotaion test on a low-grade barite ore in Guizhou[J]. Chemical Minerals and Processing, 2017, 46(7):17-20. doi: 10.16283/j.cnki.hgkwyjg.2017.07.006
GAO Y, LIU Q J, SONG J W. Flotaion test on a low-grade barite ore in Guizhou[J]. Chemical Minerals and Processing, 2017, 46(7): 17-20. doi: 10.16283/j.cnki.hgkwyjg.2017.07.006
[6] 王洪君, 戴惠新, 杨伟林, 等. 国内某低品位重晶石矿的浮选试验研究[J]. 矿产综合利用, 2015(4):42-45. WANG H J, DAI H X, YANG W L, et al. Experimental research on flotation of a low-grade barite ore in China[J]. Multipurpose Utilization of Mineral Resources, 2015(4):42-45. doi: 10.3969/j.issn.1000-6532.2015.04.011
WANG H J, DAI H X, YANG W L, et al. Experimental research on flotation of a low-grade barite ore in China[J]. Multipurpose Utilization of Mineral Resources, 2015(4): 42-45. doi: 10.3969/j.issn.1000-6532.2015.04.011
[7] 赵阳, 刘四清, 王丹, 等. 云南某低品位重晶石矿的浮选试验研究[J]. 矿产综合利用, 2015(3):36-39+31. ZHAO Y, LIU S Q, WANG D, et al. Experimental research on flotation of a low-grade barite ore in Yunnan[J]. Multipurpose Utilization of Mineral Resources, 2015(3):36-39+31. doi: 10.3969/j.issn.1000-6532.2015.03.009
ZHAO Y, LIU S Q, WANG D, et al. Experimental research on flotation of a low-grade barite ore in Yunnan[J]. Multipurpose Utilization of Mineral Resources, 2015(3): 36-39+31. doi: 10.3969/j.issn.1000-6532.2015.03.009
[8] 陈雄, 顾帼华. 重晶石浮选研究现状[J]. 矿产综合利用, 2014(4):5-8. CHEN X, GU G H. Research status of barite flotation[J]. Multipurpose Utilization of Mineral Resources, 2014(4):5-8. doi: 10.3969/j.issn.1000-6532.2014.04.002
CHEN X, GU G H. Research status of barite flotation[J]. Multipurpose Utilization of Mineral Resources, 2014(4): 5-8. doi: 10.3969/j.issn.1000-6532.2014.04.002
-
