Speciation Analysis and Risk Assessment of Heavy Metals in the Soil of a Lead-Zinc Mining Area
-
摘要:
这是一篇矿山环境工程领域的论文。土壤重金属污染影响时间长，具有较高的生物毒性，严重威胁人类健康。为了研究铅锌矿区土壤重金属污染现状和评估重金属污染风险，以江西某铅锌矿区为研究对象，采用改进BCR连续提取法分析了某铅锌矿区土壤样品重金属元素（Cu、Pb、Zn、Cd）形态，并对重金属元素相关性进行了研究，利用风险评价编码法和次生相与原生相分布比值法评价了重金属元素的环境风险。结果表明：铅锌矿区土壤中Cu、Zn、Cd、Pb元素全量超标，Cu、Zn、Pb元素以残渣态为主，相较于Cu、Zn、Pb元素，土壤样品中Cd元素酸可提取态含量高，生物有效性强，Cd元素污染严重。矿区土壤样品中Cu、Zn、Pb元素残渣态含量均与全量呈极显著正相关，Cd元素残渣态与全量相关性不显著；酸可提取态中Cu、Zn、Cd、Pb元素含量呈极显著正相关，酸可提取态与pH值呈负相关。风险评价编码法和次生相与原生相分布比值法分析的结论较为一致，均为Cd元素污染严重，环境风险高，Cu、Pb、Zn元素污染较轻，环境风险低。本文可为铅锌矿区土壤重金属污染防治提供参考。
Abstract:This is a paper in the field of mining environmental engineering. Heavy metal pollution in soil has a long-time impact, with high biological toxicity and serious threat on human health. In order to study the present situation of soil heavy metal pollution in a lead-zinc mining area and assess its risk, a lead-zinc mining area was taken in Jiangxi as the study object, and the speciation contents of heavy metal elements (Cu, Pb, Zn, Cd) in the soil samples of a lead-zinc mining area were analyzed by themodified BCR successive extraction, and the correlation of heavy metal elements was studied. The environmental risk of heavy metal elements was evaluated by the method of risk assessment coding (RAC) and ratio of secondary phase and primary phase(RSP). The results showed that: The Cu, Zn, Cd and Pb elements in the soil of the lead-zinc mining area exceeded the standard, and the Cu, Zn and Pb elements were mainly in residual state. Compared with Cu, Zn and Pb, Cd element had a higher content of acid extractable state, and its bioavailability was strong, so the pollution of Cd element was serious. The residual-state contents of Cu, Zn and Pb in the soil samples of the mining area were significantly positively correlated with the total contents, while the residual-state contents of Cd were not significantly correlated with the total contents. The contents of Cu, Zn, Cd and Pb in the acid extractable state were significantly positively correlated, but the contents of acid extractable state was negatively correlated with pH value. The conclusion of risk assessment coding method and ratio method of secondary phase and primary phase was relatively consistent, which showed that the pollution of Cd element was serious with a high environmental risk, while that of Cu, Pb, Zn elements was relatively light with a low environmental risk. This paper is expected to provide reference for the prevention and control of soil heavy metal pollution in the lead-zinc mining area.
-
-
表 1 样品采集信息
Table 1. Sample collection information
矿区位置 样品编号 采样点描述 尾矿库下游 TRYP-1 尾矿库下游约50 m农田，表层土 TRYP-2 尾矿库下游约50 m农田，取样深度40~60 cm TRYP-3 尾矿库下游约50 m农田，取样深度100~120 cm TRYP-4 尾矿库下游约400 m农田内 TRYP-5 尾矿库下游约1600 m农田，表层土 TRYP-6 尾矿库下游约3200 m农田，表层土 TRYP-7 已复垦尾矿库下游约400 m农田，表层土 排土场下游 TRYP-8 排土场下游约400 m荒地，表层土 TRYP-9 排土场下游约1000 m农田内，表层土 TRYP-10 排土场下游约1200 m菜地内，表层土 TRYP-11 排土场下游约1800 m农田内，表层土 对照区 TRYP-12 位于矿区上游约1000 m，基本不受矿区影响，表层土
下载: 导出CSV
表 2 样品中重金属含量平均值描述性统计
Table 2. Statistic results of heavy metals in soil
元素 全量 酸可
提取态可还
原态可氧
化态残渣态 回收率*/% 农用地土壤污染风险筛选值
（GB15618-2018）重金属元素
平均超标倍数Cu 59.26 2.37 1.41 7.38 47.73 99.38 50 1.19 Zn 321.09 26.86 13.81 12.24 265.87 99.28 200 1.61 Cd 0.89 0.45 0.14 0.04 0.26 99.52 0.4 2.23 Pb 186.76 8.84 8.58 15.77 152.07 99.19 100 1.87 注：表2中重金属元素含量平均值和标准限值单位均为mg·kg-1，回收率*=重金属各形态组分含量之和/重金属全量×100%
下载: 导出CSV
表 3 重金属元素不同形态含量与全量相关性分析
Table 3. Correlation analysis between different forms and contents of heavy metals elements
元素 因素 全量 酸可提取态 可还原态 可氧化态 残渣态 pH值 Cu 全量 1 酸可提取态 0.619* 1 可还原态 0.218 -0.323 1 可氧化态 0.202 0.034 0.651* 1 残渣态 0.978** 0.575 0.116 0.011 1 pH 0.203 -0.321 0.048 0.073 0.233 1 Zn 全量 1 酸可提取态 0.590* 1 可还原态 0.104 0.314 1 可氧化态 0.153 0.047 0.739** 1 残渣态 0.991** 0.491 0.014 0.108 1 pH -0.102 -0.440 -0.062 0.384 -0.059 1 Cd 全量 1 酸可提取态 0.815** 1 可还原态 0.629* 0.409 1 可氧化态 0.681* 0.502 0.962** 1 残渣态 0.331 -0.054 -0.260 -0.259 1 pH 0.297 -0.114 0.262 0.255 0.481 1 Pb 全量 1 酸可提取态 0.767** 1 可还原态 0.542 0.333 1 可氧化态 0.469 0.377 0.525 1 残渣态 0.995** 0.731** 0.491 0.397 1 pH -0.140 -0.467 -0.150 -0.042 -0.102 1 注：*为显著性相关（显著性水平＜0.05），**为极显著性相关（显著性水平＜0.01）。
下载: 导出CSV
表 4 相同提取态下重金属元素相关性分析
Table 4. Correlation analysis of heavy metals elements in the same form
元素形态 因素 Cu Zn Cd Pb pH值 酸可提取态 Cu 1 Zn 0.836** 1 Cd 0.641* 0.820** 1 Pb 0.717** 0.851** 0.705** 1 pH -0.321 -0.440 -0.114 -0.467 1 可还原态 Cu 1 Zn 0.166 1 Cd -0.188 0.076 1 Pb 0.197 0.006 0.010 1 pH 0.048 -0.062 0.262 -0.150 1 可氧化态 Cu 1 Zn 0.596* 1 Cd 0.232 0.603* 1 Pb 0.452 0.674* 0.690* 1 pH 0.073 0.384 0.255 -0.042 1 残渣态 Cu 1 Zn 0.816** 1 Cd 0.443 0.166 1 Pb 0.751** 0.856** 0.185 1 pH 0.233 -0.059 0.481 -0.102 1 全量 Cu 1 Zn 0.839** 1 Cd 0.527 0.619* 1 Pb 0.737** 0.838** 0.453 1 pH 0.203 -0.102 0.297 -0.140 1 注：*为显著性相关（显著性水平＜0.05），**为极显著性相关（显著性水平＜0.01）。
下载: 导出CSV
表 5 土壤重金属RAC值与风险程度
Table 5. RAC values and risk of heavy metals in soil
元素 RAC平均值/% RAC＜1% 1%≤RAC＜10% 10%≤RAC＜30% 30%≤RAC＜50% RAC≥50% 数量 比例/% 数量 比例/% 数量 比例/% 数量 比例/% 数量 比例/% Cu 4.02 1 8.33 11 91.67 0 0 0 0 0 0 Zn 8.32 0 0 8 66.67 4 33.33 0 0 0 0 Cd 51.05 0 0 0 0 1 8.33 6 50.00 5 41.67 Pb 3.60 0 0 11 91.67 1 8.33 0 0 0 0 风险等级 无风险 低风险 中等风险 高度风险 极高风险
下载: 导出CSV
表 6 土壤重金属RSP值与污染程度
Table 6. RSP values and pollution degree of soil heavy metals
元素 RSP平均值 RSP＜1 1≤RSP＜2 2≤RSP＜3 RSP≥3 数量 比例/% 数量 比例/% 数量 比例% 数量 比例/% Cu 0.31 11 91.67 1 8.33 0 0 0 0 Zn 0.29 12 100 0 0 0 0 0 0 Cd 6.80 1 8.33 4 33.34 1 8.33 6 50.00 Pb 0.31 12 100 0 0 0 0 0 0 风险等级 无 轻度 中度 重度
下载: 导出CSV
-
