Efficient Separation of Zn2+ and Cd2+ Ions in Solution by the Mechanochemically Activated Talc
-
摘要:
天然硅酸盐粘土矿物被普遍应用于净化重金属污染废水及其资源回收。本实验研究主要采用机械力活化技术，有效地提高天然粘土矿物滑石的化学反应活性，实现了混合溶液中锌镉离子的高效分离和回收。滑石在机械力活化后可以释放出大量镁离子和氢氧根离子，并在硫酸根离子的作用下，选择性地将锌离子以羟硫硅锌石的形式沉淀下来。通过调节机械力活化强度、反应温度、滑石用量和金属盐种类等影响因素，获得了较佳条件下锌离子去除量112.01 mg/g，镉离子去除量16.92 mg/g的良好分离效果。机械力活化天然硅酸盐粘土矿物，使其在处置重金属废水及分离回收多金属再生资源中呈现良好的应用潜力。
Abstract:Natural silicate clay minerals are widely used in the purification of heavy metal polluted wastewater and resource recovery. In this case, mechanochemical activation technology has been used to effectively improve the chemical reaction activity of natural clay mineral talc, and enable the efficient separation and recovery of Zn2+ and Cd2+ ions in mixed solution. A large number of Mg2+ and OH- were released from the structure of talc, after mechanochemical activation, and Zn2+ can be selectively precipitated in the form of bechererite, in the presence of SO42-. By adjusting the mechanochemical activation intensity, reaction temperature, talc dosage and metal salt type, etc., a considerable separation effect with 112.01 mg/g of Zn2+ removal and 16.92 mg/g of Cd2+ removal was obtained, at the optimum conditions. The mechanochemical activation of clay minerals in nature shows a favorable application potential in the disposal of heavy metal wastewater as well as the separation and utilization of renewable polymetallic resources.
-
-
表 1 滑石原矿的多元素组分/%
Table 1. Components of multi-elements of the raw talc
MgO Al2O3 CaO MoO3 SrO Cl BaO SiO2 P2O5 TiO2 Fe2O3 SO3 K2O 32.09 0.392 1.87 0.006 0.006 8 0.051 1.75 61.23 0.018 0.022 0.966 7 1.58 0.008
下载: 导出CSV
-
[1] MESHRAM P, MISHRA A, ABHILASH, et al. Environmental impact of spent lithium ion batteries and green recycling perspectives by organic acids - A review[J]. Chemosphere, 2020, 242:125291. doi: 10.1016/j.chemosphere.2019.125291
[2] 罗丽萍, 刘应冬, 范良千. 攀枝花地区煤矸石中重金属元素浸出行为研究[J]. 矿产综合利用, 2021(4):59-65.LUO L P, LIU Y D, FAN Q L. Leaching behavior of main heavy metal from coal gangue in the Panzhihua[J]. Multipurpose Utilization of Mineral Resources, 2021(4):59-65. doi: 10.3969/j.issn.1000-6532.2021.04.009
LUO L P, LIU Y D, FAN Q L. Leaching behavior of main heavy metal from coal gangue in the Panzhihua[J]. Multipurpose Utilization of Mineral Resources, 2021(4):59-65. doi: 10.3969/j.issn.1000-6532.2021.04.009
[3] 李杰锋. 煤矿复垦区土壤重金属形态分布与富集污染研究[J]. 矿产综合利用, 2022(1):116-120.LI J F. Study on distribution of heavy metals in soil and concentrated pollution in coal mine reclamation area[J]. Multipurpose Utilization of Mineral Resources, 2022(1):116-120. doi: 10.3969/j.issn.1000-6532.2022.01.014
LI J F. Study on distribution of heavy metals in soil and concentrated pollution in coal mine reclamation area[J]. Multipurpose Utilization of Mineral Resources, 2022(1):116-120. doi: 10.3969/j.issn.1000-6532.2022.01.014
[4] JOSEPH L, JUN B M, FLORA J, et al. Removal of heavy metals from water sources in the developing world using low-cost materials: A review[J]. Chemosphere, 2019, 229:142-159. doi: 10.1016/j.chemosphere.2019.04.198
[5] 郭娟, 崔荣国, 闫卫东, 等. 2021年中国矿产资源形势回顾与展望[J]. 中国矿业, 2022, 31(1):11-17.GUO J, CUI R G, YAN W D, et al. Outlook and overview of mineral resources situation of China in 2021[J]. China Mining Magazine, 2022, 31(1):11-17. doi: 10.12075/j.issn.1004-4051.2022.01.025
GUO J, CUI R G, YAN W D, et al. Outlook and overview of mineral resources situation of China in 2021[J]. China Mining Magazine, 2022, 31(1):11-17. doi: 10.12075/j.issn.1004-4051.2022.01.025
[6] LECLER M T, ZIMMERMANN F, SILVENTE E, et al. Exposure to hazardous substances in cathode ray tube (CRT) recycling sites in France[J]. Waste Management, 2015, 39(may):226-235.
[7] 李姣, 刘璐, 杨斌, 等. 镉及镉与铁、锌互作对水稻生长的影响[J]. 华北农学报, 2018, 33(1):217-223.LI J, LIU L, YANG B, et al. Effects of cadmium concentration and interaction of cadmium with iron and zinc interaction on rice growth[J]. Acta Agriculturae Boreali-Sinica, 2018, 33(1):217-223. doi: 10.7668/hbnxb.2018.01.031
LI J, LIU L, YANG B, et al. Effects of cadmium concentration and interaction of cadmium with iron and zinc interaction on rice growth[J]. Acta Agriculturae Boreali-Sinica, 2018, 33(1):217-223. doi: 10.7668/hbnxb.2018.01.031
[8] 王海峰, 张研, 任辉. 镉、锌制剂联合应用抑制肝细胞癌生长和转移的实验研究[J]. 中国实验诊断学, 2006, 10(10): 1197-1199.WANG H F, ZHANG Y, REN H. Inhibition of growth and metastasis of human hepatocellular carcinoma by cadmium and zinc preparation combined treat-ment in a nude mouse xenograftmodel[J]. Chinese Journal of Laboratory Diagnosis. 2006, 10(10): 1197-1199.
WANG H F, ZHANG Y, REN H. Inhibition of growth and metastasis of human hepatocellular carcinoma by cadmium and zinc preparation combined treat-ment in a nude mouse xenograftmodel[J]. Chinese Journal of Laboratory Diagnosis. 2006, 10(10): 1197-1199.
[9] 林秋月, 赵国良, 陈少微, 等. 硫酸铵-锌试剂-Tween-80体系萃取分离铜(Ⅱ)、钴(Ⅱ)、镍(Ⅱ)、锌(Ⅱ)、镉(Ⅱ)、锰(Ⅱ)[J]. 分析化学, 2000, 28(6):706-708.LIN Q Y, ZHAO G L, CHEN S W, et al. Extraction separation of copper(Ⅱ), cobalt(Ⅱ), nickel(Ⅱ), zinc(Ⅱ), cadmium(Ⅱ) and manganese(Ⅱ) using ammonium[J]. Chinese Journal of Analytical Chemistry, 2000, 28(6):706-708. doi: 10.3321/j.issn:0253-3820.2000.06.011
LIN Q Y, ZHAO G L, CHEN S W, et al. Extraction separation of copper(Ⅱ), cobalt(Ⅱ), nickel(Ⅱ), zinc(Ⅱ), cadmium(Ⅱ) and manganese(Ⅱ) using ammonium[J]. Chinese Journal of Analytical Chemistry, 2000, 28(6):706-708. doi: 10.3321/j.issn:0253-3820.2000.06.011
[10] 刘新芳, 何鼎胜, 马铭, 等. 三正辛胺-仲辛醇-煤油组合液膜分离镉锌的研究[J]. 无机化学学报, 2003.LIU X F, HE D S, MA M, et al. Study on separation of binary cadmium(Ⅱ) and zinc(Ⅱ) by a tri-n-octylamine-secondary octyl alcohol-kerosene hybrid liquid membrane[J]. Chinese Journal of Inorganic Chemistry, 2003.
LIU X F, HE D S, MA M, et al. Study on separation of binary cadmium(Ⅱ) and zinc(Ⅱ) by a tri-n-octylamine-secondary octyl alcohol-kerosene hybrid liquid membrane[J]. Chinese Journal of Inorganic Chemistry, 2003.
[11] 祝旭初. 铬(Ⅵ)-二乙基二硫代甲酸钠共沉淀-原子吸收光谱法测定环境水样中铁、锰、锌、镉[J]. 理化检验(化学分册), 2010, 46(1):84-86.ZHU X C. AAS Determination of iron, manganese, zinc, cadmium in environmental water samples after enrichment by coprecipitaion with Cr(Ⅵ)-DDTC[J]. Physical Testing and Chemical Analysis Part B: Chemical Analysis, 2010, 46(1):84-86.
ZHU X C. AAS Determination of iron, manganese, zinc, cadmium in environmental water samples after enrichment by coprecipitaion with Cr(Ⅵ)-DDTC[J]. Physical Testing and Chemical Analysis Part B: Chemical Analysis, 2010, 46(1):84-86.
[12] 张继华. 化学沉淀法处理磷化废水[J]. 工业水处理, 2000(5):43-44.ZHANG J H. Treatment of phosphate coating wastewater by chemical precipitation[J]. Industrial Water Treatment, 2000(5):43-44. doi: 10.3969/j.issn.1005-829X.2000.05.017
ZHANG J H. Treatment of phosphate coating wastewater by chemical precipitation[J]. Industrial Water Treatment, 2000(5):43-44. doi: 10.3969/j.issn.1005-829X.2000.05.017
[13] BURAKOV, ALEXANDER E, et al. Adsorption of heavy metals on conventional and nanostructured materials for wastewater treatment purposes: a review[J]. Ecotoxicology & Environmental Safety, 2018(148):702-712.
[14] 杨华明, 邱冠周, 王淀佐. 滑石粉超细粉碎过程的结构变化[J]. 硅酸盐学报, 1999, 27(5):580-584.YANG H M, QIU G Z, WANG D Z. Structural changes of talc powder during ultrafine grinding[J]. Journal of the Chinese Ceramic Society, 1999, 27(5):580-584. doi: 10.3321/j.issn:0454-5648.1999.05.012
YANG H M, QIU G Z, WANG D Z. Structural changes of talc powder during ultrafine grinding[J]. Journal of the Chinese Ceramic Society, 1999, 27(5):580-584. doi: 10.3321/j.issn:0454-5648.1999.05.012
[15] 欧阳燎原, 陈渊淦, 汪惠惠, 等. 不同矿浆温度下滑石表面甲基纤维素脱附行为研究[J]. 矿产综合利用, 2022 (2): 66-68.OUYANG L Y, CHEN Y J, WANG H H , et al. The desorption behavior of methylcellulose from talc at different temperature of pulp[J]. Multipurpose Utilization of Mineral Resources, 2022 (2): 66-68.
OUYANG L Y, CHEN Y J, WANG H H , et al. The desorption behavior of methylcellulose from talc at different temperature of pulp[J]. Multipurpose Utilization of Mineral Resources, 2022 (2): 66-68.
[16] LI Z, CHEN M, QU J, et al. Surface modification of basic copper carbonate by mechanochemical processing with sulfur and ammonium sulfate[J]. Advanced Powder Technology, 2017(28):1877-1881.
[17] AKYUZ T, AKYUZ S, GULEC A. Elemental and spectroscopic characterization of plasters from fatih mosque-istanbul (turkey) by combined micro-raman, FTIR and EDXRF techniques[J]. Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 2015(149):744-750.
-
