Extracting Vanadium over Iron from Direct Acid Leaching Solution of V-bearing Steel Slag by Solvent Extraction with Tertiary Amine TOA
-
摘要:
用叔胺TOA对含钒钢渣直接酸浸液进行溶剂萃取，考查了主要因素对萃钒除铁的影响，并分析了TOA的构效关系及其萃钒除铁的溶液化学行为。结果表明：在TOA体积浓度15%、初始水相pH 1.8~1.9、相比A/O为3、萃取时间3 min的最佳条件下，经4级逆流萃取，较好地实现了萃钒除铁，钒萃取率达98%，而铁则很少被共萃。TOA的N原子具有较强给电子性的弧对电子，经硫酸酸化，转化为[（C8H17）3NH]2SO4，可通过阴离子交换反应完成萃取过程；水相中的V（Ⅳ）经H2O2氧化后转化为V（Ⅴ），利用氨水中和将水相pH值提高，VO2+则转化为多种形式的阴离子；当钒以特定形式[H2V10O28]4-存在时，可获得较高的萃取率；在pH 1.2~2.4较宽范围内，钒均可以[H2V10O28]4-的形式存在，而且在此范围内增大pH值，[H2V10O28]4-浓度以及HSO4-解离度增加，钒萃取率因而提高；但当pH>1.9时，Fe（Ⅲ）会发生水解沉淀，阻碍两相分离并引起钒的共沉淀损失，对萃取极为不利；当pH < 2.0时，Fe（Ⅲ）以Fe3+形式存在，难以被TOA共萃，从而可达到萃钒除铁的目的。
Abstract:Solvent extraction of direct acid leaching solution of vanadium-bearing steel slag with tertiary amine TOA, was carried out, and the effects of the main factors on extraction of vanadium over iron were investigated. Meanwhile, the structure-activity relationship of TOA and the solution chemical behavior of extracting vanadiumover iron were analyzed. Through a 4-stage countercurrent extraction under the following optimum conditions: TOA concentration of 15 vol.%, initial aqueous phase pH of 1.8~1.9, phase ratio (A/O) of 3, and extraction time of 3 min, the extraction of vanadium over iron was well achieved, and vanadium extraction rate reached 98% whereas iron was barely extracted. N atom of TOA has a lone pair of electrons and can be an electron contributor, TOA acidified by H2SO4 to convert to [(C8H17)3NH]2SO4, can achieve extraction through anion-exchange reaction.Through oxidation by H2O2, V(Ⅳ) in aqueous phasewas oxidized to V(Ⅴ). Through neutralization by NH3·H2O to increase aqueous phase pH, VO2+ was converted to various forms of anions. When vanadium was in the specific form of [H2V10O28]4-, a higher extraction rate could be obtained. Vanadium could exist in form of [H2V10O28]4- within a wide pH range of 1.2~2.4. As the pH increased within this pH range, the concentration of [H2V10O28]4- and the dissociation of HSO4- also increased, which improved extraction rate. However, Fe(III) would be precipitated by hydrolysis at pH > 1.9, which would prevent the two phases from separating and cause a coprecipitation loss of vanadium.When pH < 2.0, Fe (Ⅲ) existed in the form of Fe3+ and could not be extracted by TOA, so the purpose of extracting vanadium over iron was realized.
-
-
表 1 给料液的化学组元
Table 1. Chemical components of the feed solution
/(g·L-1) V Fe Ti P Cr Mn 4.52 14.10 1.01 0.39 0.15 0.11 Al Si Ca Mg K Na 0.09 0.08 0.07 0.09 0.053 0.018
下载: 导出CSV
表 2 最佳条件下4级逆流萃取结果
Table 2. Results of 4-stage countercurrent extraction under the optimum conditions
Items V Fe Ti P Cr Mn CF/(g·L-1) 4.52 14.10 1.01 0.39 0.15 0.11 CR/(g·L-1) 0.09 13.48 0.99 0.34 0.15 0.11 Corg/(g·L-1) 13.29 1.86 0.06 0.15 —— —— E/% 98.01 4.40 1.98 12.82 —— —— D 147.67 0.138 0.061 0.441 —— —— βV/Me —— 1070 2421 335 —— ——
下载: 导出CSV
-
[1] 叶国华, 陈子杨, 谢禹, 等. 含钒钢渣中负组元钙的净化与回收[J]. 矿产保护与利用, 2020(3): 1-6. http://kcbh.cbpt.cnki.net/WKD/WebPublication/paperDigest.aspx?paperID=5f6acd46-cff1-4d14-9a9f-1f0c16ef2379
[2] 叶国华, 童雄, 路璐. 含钒钢渣的选矿预处理及其对后续浸出的影响[J]. 中国有色金属学报, 2010, 20(11): 2233-2238. https://www.cnki.com.cn/Article/CJFDTOTAL-ZYXZ201011028.htm
[3] 叶国华, 童雄, 路璐. 含钒钢渣资源特性及其提钒的研究进展[J]. 稀有金属, 2010, 34(5): 769-775. doi: 10.3969/j.issn.0258-7076.2010.05.026
[4] 叶国华, 何伟, 路璐, 等. 常温常压下含钒钢渣直接硫酸浸钒的研究[J]. 稀有金属, 2013, 37(5): 813-819. https://www.cnki.com.cn/Article/CJFDTOTAL-ZXJS201305020.htm
[5] 谢禹, 叶国华, 左琪, 等. 含钒钢渣提钒新工艺研究[J]. 钢铁钒钛, 2019, 40(1): 69-77. https://www.cnki.com.cn/Article/CJFDTOTAL-GTFT201901023.htm
[6] ZHANG H, YE GH, LU L, et al. Thermodynamic study on sulfuric acid leaching for vanadium extraction from V-bearing steel slag [J]. Iron Steel Vanadium Titanium, 2020(1): 1-6.
[7] ZHANG YM, BAO SX, LIU T, et al. The technology of extracting vanadium from stone in china: history, current status and future prospects [J]. Hydrometallurgy, 2011, 109: 116-124. doi: 10.1016/j.hydromet.2011.06.002
[8] ZHANG WG, ZHANG T, LI TT, et al. Basic research on the leaching behavior of vanadium-bearing steel slag withtitanium white waste acid[J]. Journal of Environmental Chemical Engineering, 2021, 9: 104897. doi: 10.1016/j.jece.2020.104897
[9] AARABI-KARASGANI M, RASHCHI F, MOSTOUFI N, et al. Leaching of vanadium from LD converter slag using sulfuric acid[J]. Hydrometallurgy, 2010, 102: 14-21. doi: 10.1016/j.hydromet.2010.01.006
[10] CHEN XY, LAN XZ, ZHANG QL. Leaching vanadium by high concentration sulfuric acid from stone coal [J]. Transactions of Nonferrous Metals Society of China, 2010, 20: 123-126. doi: 10.1016/S1003-6326(09)60108-4
[11] YE GH, HU YB, TONG X, et al. Extraction of vanadium from direct acid leaching solution of clay vanadium ore using solvent extraction with N235 [J]. Hydrometallurgy, 2018, 177: 27-33. doi: 10.1016/j.hydromet.2018.02.004
[12] 叶国华. 从含钒钢渣中提取V2O5的新工艺与机理研究[D]. 昆明: 昆明理工大学, 2010.
[13] 张爽. 从黏土钒矿直接酸浸液中萃取提钒的研究[D]. 昆明: 昆明理工大学, 2015.
[14] LI W, ZHANG YM, LIU T, et al. Comparison of ion exchange andsolvent extraction in recovering vanadium from sulfuric acid leach solutions of stonecoal [J]. Hydrometallurgy, 2013, 131: 1-7. http://www.sciencedirect.com/science/article/pii/S0304386X12002162
[15] 余彬, 孙朝晖, 鲜勇, 等. 钒渣无焙烧酸浸液萃取分离试验研究[J]. 钢铁钒钛, 2014, 35(5): 1-6. https://www.cnki.com.cn/Article/CJFDTOTAL-GTFT201405002.htm
[16] 曹威, 张一敏, 包申旭, 等. N235从石煤提钒酸浸液中直接萃取钒[J]. 有色金属(冶炼部分), 2015(4): 34-37. doi: 10.3969/j.issn.1007-7545.2015.04.009
[17] 胡艺博, 叶国华, 左琪, 等. 石煤钒矿酸浸液提钒萃取剂的研究进展与前景[J]. 矿产综合利用, 2020(1): 10-15. doi: 10.3969/j.issn.1000-6532.2020.01.002
[18] 陈子杨, 叶国华, 左琪, 等. 有机胺类萃取剂构效关系及其萃钒的研究进展[J]. 钢铁钒钛, 2020, 41(3): 8-15. https://www.cnki.com.cn/Article/CJFDTOTAL-GTFT202003002.htm
[19] YANG X, ZHANG YM, BAO SX, et al. Separation and recovery of vanadiumfrom a sulfuric-acid leaching solution of stone coal by solvent extraction using trialkylamine [J]. Separation and Purification Technology, 2016, 164: 49-55. doi: 10.1016/j.seppur.2016.03.021
[20] CHAGNES A, RAGER M N, COURTAUD B, et al. Speciation of vanadium(V) extracted from acidic sulfate media by trioctylamine in n-dodecane modified with 1-tridecanol [J]. Hydrometallurgy, 2010, 104: 20-24. doi: 10.1016/j.hydromet.2010.04.004
[21] 刘铭, 周雍茂. 用N235-TBP混合体系从硫酸盐溶液中协同萃取除铁[J]. 中国有色金属学报, 2005, 15(10): 1648-1654. doi: 10.3321/j.issn:1004-0609.2005.10.029
-
