GENETIC MECHANISMS OF THE COLLAPSING GEOHAZARD ON THE LINGSHAN ISLAND AND THEIR RISK ASSESSMENT
-
摘要:
灵山岛是山东省青岛市西海岸新区南部黄海近岸海域中的一个小岛，位于苏鲁造山带内，岛上最典型地层为早白垩世深海相复理石，发育了大量软沉积物变形现象。分析了灵山岛省级自然保护区地质灾害成因机理，总结了其坍塌特征及评价方法，划分其崩塌地质灾害等级，最终对研究区进行危险性评价。研究发现，灵山岛老虎嘴崩塌威胁危害程度为中等，灵山岛唐泉村崩塌威胁危害程度为小型，可为后续类似工程提供参考。
Abstract:The Lingshan Island is a small island located in the nearshore area of the Yellow Sea to the south of Huangdao District of Qingdao City, Shandong Province. It is tectonically belonging to the Sulu orogenic belt. The island is dominated by Early Cretaceous complex rocks of deep-sea facies, and a large number of soft sediment deformation phenomena have been observed. This paper focuses on the genetic mechanism of geological disasters at the Lingshan Island Provincial Nature Reserve, and summarized are the collapse features and their evaluation method. Risk assessment suggests that the risk of Laohuzui collapse on the Island is moderate, while the risk at the Tangquan Village is small. The evaluation method used in this paper may provide a reference for similar projects.
-
-
表 1 灵山岛老虎嘴崩塌危岩体弹跳距离
Table 1. Critical rock jumping distances at Laohuzui，Lingshan Island
编号参数 H坡高/m α崩塌坡度/（°） F斜坡平均阻力系数 V崩塌体沿斜坡运动的速度/（m/s） β崩塌体的弹跳抛射角/（°） S弹跳距离/m WY1 17 30 0.3 15.70 87.85 14.49 WY2 18 55 0.3 17.09 68.15 83.10 WY3 15 60 0.3 15.81 63.75 101.09 WY4 22 60 0.3 19.14 59.81 137.70 WY5 16 80 0.3 17.24 29.25 121.25 WY6 15 69 0.3 16.20 49.96 184.35 WY7 8 80 0.3 12.19 32.83 165.48 WY8 10 32 0.3 12.09 95.20 4.36 WY9 11 30 0.3 12.63 94.46 2.89 WY10 5 59 0.3 9.10 78.20 36.63
下载: 导出CSV
表 2 老虎嘴勘查区坡顶散落孤石情况
Table 2. Scattered boulders at the top of the Laohuzui exploration area
序号 长/m 宽/m 高/m 方量/m3 1 4 3 1 12.00 2 5.6 2 1.5 16.80 3 1.2 2.7 0.7 2.27 4 2.8 1.3 0.6 2.18 5 6 3 2.8 50.40 6 5 2 0.6 6.00 7 1.6 3 0.8 3.84 8 5.6 3 1.5 25.20 9 5 4.3 0.5 10.75 10 5 3.7 1.2 22.20 11 0.8 0.9 1.5 1.08 12 1.5 0.8 0.9 1.08 13 5 2.8 0.8 11.20 14 3 3 0.6 5.40 15 1.7 1.9 0.8 2.58 16 4 3.2 0.7 8.96 17 2.6 2 0.6 3.12 18 2 1.2 0.6 1.44 19 1.7 1.7 0.3 0.87 20 3 2.5 1.6 12.00 21 2.5 1.2 0.3 0.90 合计 200.27
下载: 导出CSV
-
[1] 董晓朋,吕洪波,张星,等. 山东灵山岛早白至世复理石软沉积物变形期次解析[J]. 地质论评,2013,59(6):1060-1067.
[2] IRVING E,WARD M A. A statistical model of the geomagnetic field[J]. Pure and Applied Geophysics,1964,57(1):47-52.
[3] 董晓朋,吕洪波,张星,等. 灵山岛北端早白奎世复理石中的滑塌断崖[J]. 地质论评,2014,60(4):771-779.
[4] 吕洪波,王俊,张海春. 山东灵山岛晚中生代滑塌沉积层的发现及区域构造意义初探[J]. 地质学报,2011,85(6):938-946.
[5] JACKSON M,TAUXE L. Anisotropy of magnetic susceptibility and remanence:developments in the characterization of tectonic sedimentary and igneous fabric.[J]. Reviews of Geophysics,1991,29(S1):371-376. doi: 10.1002/rog.1991.29.s1.371
[6] SUD C,QIAOX F,SUNA P,et al. Large earthquake‐triggered liquefaction mounds and a carbonate sand volcano in the Mesoproterozoic Wumishan Formation,Beijing,North China[J]. Geological Journal,2014,49(1):69-89.
[7] GERAINT O,MASSIMO M,PEDRO A. Recognising triggers for soft-sediment deformation:current understanding and future directions[J]. Sedimentary Geology,2010,235(3):133-140.
[8] GIBERT L,ALFARO P,GARCÍA-TORTOSA F J,et al. Superposed deformed beds produced by single earthquakes(Tecopa Basin,California):Insights into paleoseismology[J]. Sedimentary Geology,2010,235(3):148-159.
[9] 吕洪波,张海春,王俊,等. 山东胶南灵山岛晚中生代浊积岩中发现巨大滑积岩块[J]. 地质论评,2012,58(1):80-81. doi: 10.3969/j.issn.0371-5736.2012.01.007
[10] 葛毓柱,钟建华. 灵山岛早白垩世软沉积物变形构造触发机制及其古环境意义探讨[J]. 地质论评,2017,63(4):927-940.
[11] GERAINT O,MASSIMO M. Identifying triggers for liquefaction-induced soft-sediment deformation in sands[J]. Sedimentary Geology,2010,235(3):141-147.
[12] 葛毓柱,钟建华,樊晓芳,等. 山东灵山岛滑塌体内部沉积及构造特征研究[J]. 地质论评,2015(3):634-644.
[13] 王安东,周瑶琪,闫华,等. 山东省灵山岛早白垩世软沉积物变形构造特征[J]. 古地理学报,2013,15(5):717-728. doi: 10.7605/gdlxb.2013.05.059
[14] WANG J,CHANG S C,WANG K L,et al. Geochronology and geochemistry of Early Cretaceous igneous units from the central Sulu orogenic belt:evidence for crustal delamination during a shift in the regional tectonic regime[J]. Journal of Asian Earth Sciences,2015,112:49-59. doi: 10.1016/j.jseaes.2015.09.009
[15] ZHU G,LIU G S,NIU M L,et al. Syn-collisional transform faulting of the Tan-Lu fault zone,East China[J]. International Journal of Earth Sciences,2009,98(1):135-155. doi: 10.1007/s00531-007-0225-8
[16] 李杰,金爱文,侯贵廷,等. 灵山岛早白垩世构造应力解析及区域地质意义[J]. 北京大学学报(自然科学版),2015,51(6):1069-1077.
[17] 李守军,张祥玉,赵秀丽,等. 山东省青岛市灵山岛下白垩统中发现鱼类和叶肢介化石[J]. 地质论评,2017,63(1):1-6.
[18] 刘菲菲,周瑶琪,许红,等. 灵山岛成因特征、类型及其地质构造意义[J]. 海洋地质前沿,2016,32(3):33-40.
[19] BERRA F,FELLETTI F. Syndepositional tectonics recorded by soft-sediment deformation and liquefaction structures (continental Lower Permian sediments,Southern Alps,Northern Italy):stratigraphic significance[J]. Sedimentary Geology,2010,235(3):249-263.
[20] 张岳桥,赵越,董树文,等. 中国东部及邻区早白垩世裂陷盆地构造演化阶段[J]. 地学前缘,2004(3):123-133. doi: 10.3321/j.issn:1005-2321.2004.03.014
[21] 刘忠敏,李成治,李本川,等. 应用TM卫星像片对灵山岛地质构造及边坡稳定性的调查[J]. 海洋科学,1990(6):35-38.
[22] 陈洪凯,鲜学福,唐红梅,等. 危岩稳定性分析方法[J]. 应用力学学报,2009,26(2):278-272.
[23] 郑生庆, 郑颖人, 黄强, 等. GB 50330—2013, 建筑边坡工程技术规范[S]. 北京: 中国建筑工业出版社.
[24] 郭希哲, 徐开祥, 黄学斌, 等. DZ/T0221—2006. 崩塌、滑坡、泥石流监测规范[S]. 北京: 地质出版社.
[25] 殷跃平, 颜宇森, 高娇娇, 等. DZ/T 0286—2015. 地质灾害危险性评估规范[S]. 北京: 中国标准出版社.
-
